600W/2-channel Compact Amplifier with DSP and Dante™
Overview
MEZZO 602 ADheralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size. Exceedingly flexible, "A" versions of MEZZO offer remote control and monitoring of all the vital functions. The small form factor allows it to be mounted anywhere thanks to the included mounting kit. Two channel versions of MEZZO also feature 2 line-level outputs, further extending routing options.
MyPowersoft services are available for this product.
Features
- Multiple mounting options
- Auto-Setup
- Power-sharing
- Full remote control via 3rd party controls
Specifications
Documents
Data sheetsMEZZO Series datasheetMEZZO Series datasheet CNUSER GUIDESMEZZO Series - Plenum Mount AC Adapter quick guideMEZZO Series User Guide - MultilingualTHERMAL & CURRENTMEZZO Series Current Draw & Thermal DissipationTECHNICAL NOTESApplication Note - Dynamic Music Distribution Design GuideApplication Note - HealthPlusApplication Note - Amplifiers Backup strategy and Startup timesApplication Note - Limiters: basic concept and operationsApplication Note - Power SharingApplication Note - Line Integrity Monitoring and Pilot TonesApplication Note - VCA Operation and remote Off GPIApplication Note - Interactive Tuning Plugin | Armonía PluginApplication Note - Powersoft Amplifiers and AoIP (Dante-AES67)BUILDING INFORMATION MODELING - BIMBIM - MEZZO SeriesA&E SPECIFICATIONSMEZZO Series A&E SpecsSOFTWAREArmoníaPlusCertificationsRoHsChina Declaration of Conformity PowersoftRoHsCE Declaration of Conformity PowersoftCCC Certificate 2020010802300956CB Certificate NL DEKRA – MEZZO SeriesCSA Certificate 80179282Declaration of Conformity DoC Powersoft – MEZZO SeriesCE Verification of Conformity AT-LVD-838-0123ACE Verification of Conformity AT-EMC-838-0323AUK Declaration of Conformity DoC Powersoft – MEZZO SeriesEPA Declaration of Conformity PowersoftFCC Supplier’s Declaration of Conformity SDoC Powersoft - MEZZO SeriesREACH DoC Powersoft
Engineered around uptime
Powersoft’s DSP implements a complete audio management system that provides a unique level of control and can be used to set the tone of any space.
Our current line of amplifier offers Dante™ either as standard or as an option on any model, for audio over IP networking.
Controlling and monitoring of a Powersoft amplifier can be done through ArmoníaPlus.
Power Sharing enables part of the power to be shared across all output channels so that it can be used where it is needed the most.
MEZZO Series - all models
| Model | Total power | Per channel | Channels | Form factor | AoIP |
|---|---|---|---|---|---|
| MEZZO 604 A+ | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 324 A+ | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 602 A+ | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 322 A+ | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 602 A | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | - |
| MEZZO 602 AD | 600 W | 200 W @ 2 Ω 300 W @ 4 Ω 300 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 604 AD | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 604 A | 600 W | 150 W @ 2 Ω 150 W @ 4 Ω 150 W @ 8 Ω | 4 | - | - |
| MEZZO 324 AD | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | Dante / AES67 |
| MEZZO 324 A | 320 W | 80 W @ 2 Ω 80 W @ 4 Ω 80 W @ 8 Ω | 4 | - | - |
| MEZZO 322 AD | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | Dante / AES67 |
| MEZZO 322 A | 320 W | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω | 2 | - | - |
Features
- Multiple mounting options
- Auto-Setup
- Power-sharing
- Full remote control via 3rd party controls
Specifications
| Output power per channel | |||
|---|---|---|---|
| Output power per channel | 200 W @ 2 Ω | 300 W @ 4 Ω | 300 W @ 8 Ω |
| Maximum power-sharing capacity per channel | 400 W @ 4 Ω | 600 W @ 8 Ω | |
| Max output voltage / current | |||
| Maximum unclipped output voltage | 142 Vpeak | ||
| Maximum output current | 15.6 Apeak | ||
| AC main power | |||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
| Operating voltage | 90 V - 264 V | ||
| Power consumption/current draw | |||
| Idle | 115 V: 12 W - 0.24 A | 230 V: 14 W - 0.19 A | |
| 1/8 of max output power @ 4 Ω | 115 V: 126 W - 1.13 A | 230 V: 123 W - 0.64 A | |
| Thermal dissipation* | |||
| Idle | 115 V: 40 BTU/h | 230 V: 46 BTU/h | |
| 1/8 of max output power @ 4 Ω | 115 V: 112 BTU/h | 230 V: 123 BTU/h | |
