OEM Active Speaker

Reference designs for active loudspeakers

Overview

OEM active speaker configurations pair Powersoft amplifier modules with passive transducers to build fully active loudspeakers.

From two-way and three-way systems to subwoofers, 2.1 and 1.1 configurations, double subwoofers and M-Force infrasound, each reference design shows the recommended DigiMod, LiteMod or IpalMod module for the job.

Configurations

M-Force Sub

Harness the force of the M-Force transducer with dedicated designs.

Details

Double Subwoofers

Two subwoofers driven for maximum output and control.

Details

Subwoofer

Single subwoofer designs with DigiMod, IpalMod and LiteMod examples.

Details

2.1 System

Two satellites plus a subwoofer on a single module.

Details

1.1 System

One full-range channel driven by a LiteMod module.

Details

3 Way System

Three-way active loudspeaker reference designs.

Details

2 Way System

Two-way active loudspeaker reference designs.

Details
