LiteMod 4HC

Flexible 4-channel amplifier module

Powersoft_ICONS_features-black_PFC
Powersoft_ICONS_features-black_SRM
Powersoft_ICONS_features-black_DSP-optional
GreenPower@2x

OVERVIEW

LiteMod 4HC is an extremely versatile amplification platform integrating PFC equipped power supply for universal mains operation and 4 output stages delivering up to 2400W total.

LiteMod 4HC boosts flexibility, being configurable as four, three, two channels, or single high power output channel and supporting 2Ω operation. It can be used in high channel count applications, three way and two way designs, subwoofer + satellite systems.

The pristine sonic performance is obtained in conjunction with the ease of use, in a compact solution.

Compatible with the majority of DSP solutions available from Powersoft, the LiteMod 4HC performances can be easily tailored and controlled through Powersoft’s ArmoníaPlus making all kind of processing tools easily available.

MyPowersoft services are available for this product

  • 4ch amp with bridge, parallel and parallel bridge configuration capabilities
  • Suitable for subs, 2/3-way systems as well as 2/4/8ch OEM rack amps
  • 78Vp , 140VpPBTL max voltage , 30Ap , 60Apparallel max current
General
Output power
Single-Ended Mode (SE)750 W @ 4 Ω
Bridge Mode (BTL)1400 W @ 8 Ω800 W @ 16 Ω
Parallel Mode (PTL)1400 W @ 2 Ω
Parallel Bridged Mode (PBTL)2400 W @ 4 Ω
Max output voltage / current
Single-Ended Mode (SE)78 Vpeak / 30 Apeak
Bridge Mode (BTL)156 Vpeak / 30 Apeak
Parallel Mode (PTL)78 Vpeak / 60 Apeak
Parallel Bridged Mode (PBTL)156 Vpeak / 60 Apeak
AC main power
Power supplyUniversal, regulated switch mode with PFC (Power Factor Correction)
Rated Power Supply Voltage100-240 V ±10%, 50-60 Hz
Operating voltage90 V – 264 V
Power consumption
Standby< 1 W (with an aux load < 100 mW)
Idle≤ 10.2 W @ 100-240 V AC
Rated Load (1/4 Max Power @ 8 Ω)700 W
THERMAL
Operating temperature range0° – 45° C – 32° – 113° F
Thermal dissipation
1/8 of max output power @ 4 Ω115 V: 251 BTU/h230 V: 241 BTU/h
